Article: 2674
| Field | Meaning |
| Model Number | ITP-630 |
| Assembly design | One-piece extruder |
| Screw | Single screw |
| Clutch system | Full engagement |
| Screw channel structure | Deep screw |
| Exhaust | Without exhaust |
| Automation | Automatic |
| Computerized | Computerized |
| Material | Q235 and stainless steel |
| Certification | ISO9001 |
| Advantages | High speed |
| Model | SJ-90/38 |
| Colour | Customizable |
| Form | Chrome plating |
| Packaging for transportation | PE film and wooden box |
| Specification | 315-630 mm |
| Brand name | Interplast Machinery |
| Country of origin | Qingdao |
| HS Code | 84772090 |
| Production capacity | 900 kg/h |
Product Description
Extrusion line for the production of pipes SJ-90/38 for water supply and sewerage from PE with high efficiency
The HDPE plastic pipe extrusion line for water supply uses a high-speed extruder with high efficiency and energy saving. The extruder has water cooling and a material loading device with dosing. The single screw extruder and traction machine use imported AC frequency conversion speed control devices, the vacuum pump and traction motor are made of high-quality products. The tractor has drives with two, three, four, six, eight, ten and twelve claws. Chipless cutting, saw blade cutting or planetary cutting are available. The installation is characterized by reliable performance and high productivity.
Pipe range
| Pipe range (mm) | The extruder | Extruder power | Extrusion capacity (kg/h) | Max. production speed (m/min) |
| 16-63 | ¢65 mm | AC45 kW | 80-120 | 18 |
| 20-110 | ¢65 mm | AC55 kW | 100-150 | 12 |
| 75-160 | ¢75 mm | AC110 kW | 250-300 | 6 |
| 90-250 | ¢75 mm | DC160 kW | 250-300 | 6 |
| 110-315 | ¢90 mm | DC160 kW | 350-400 | 3 |
| 160-450 | ¢90 mm | DC160 kW | 350-400 | 1,2 |
| 315-630 | ¢120 mm | DC280 kW | 650-700 | 0,9 |
| 500-800 | ¢150 mm | DC335 kW | 850-900 | 0,7 |
Specifications
- High-speed single screw extruder with gravimetric feed (INOEX).
- The SJ-90/38 extruder is highly efficient for the production of PE pipes.
- The machine is equipped with a chipless high-speed cutting machine, a laser printer for marking and options for HDPE multilayer pipes.
- Head for HDPE multilayer pipes: Spiral slider.
- The vacuum calibration tank and the cooling tank are made of SS304 steel.
- The traction machine is equipped with a servo motor.
